Lumber: Sawn Products
I S O 9 0 0 2 Q U A L
I T Y
M A N A G E M E N T S Y S T E M
Produn line Sawn wood
Sleepers and small-size sleepers
Cants and cut to size stocks for friezes
and pallets
Prisms
Poles
Steaming of sawn timber in three colors:
pink, pink-red and pink-
brown.
Products description The raw
material used is hardwood.
1. HARDWOOD SAWN TIMBER UNEDGED
Dimensions Width: 25, 32, 40,
45, 50, 60, 75, 95 mm
Length: 1 300 - 4 000 mm
Quality meets the STN 491010, 491012
standards; Technical Specification (hereinaher only
TP)
No. 8, Drevounia Bratislava
Dimensions of the unedged sawn timber
and dimensions of the edged sawn timber can be
adjus
ted upon the client's request.
2. SLEEPERS
Dimensions 15 x 26 x 250/260
cm also available with upper predrilling
15 x24x250/260 cm
15 x 22 x 250/260 cm
Quality meets the STN 491408 standard.
SMALL - SIZE SLEEPERS
Dimensions 12 x 10 x 100 to
160 cm
14x 12x 100to 150cm
14x20x 120to 160cm
15x20x 120to 160cm
Quality meets the STN 491 408 standard.
RAIL SWITCH SLEEPERS
Dimensions 15 x 26 x 270 to
410 cm
Quality meets the STN 491406 standard.
GIRDERS FOR BRIDGES
Dimensions 24 x 24 x 250/260
cm; 24 x 26 x 250/260 cm
Quality meets the STN 491404 standard.
Dimensions con be obtested upon
the
client's request.
S A W N
P R O D U T S
I S O 9 0 0 2 Q U A L I T Y
M A N A G E M E N T
S Y S T E M
3. GANTS AND CUT TO SIZES FOR FRIEZES
Dimensions Width of the cants made
from sawn timber: 25, 32, 40, 45 and 50 mm
Length: 200 to 2400 mm
Quality meets the STN 491511 standard,
TP2 Drevounia Bratislava; the STN 4915 21
standard,
TP3 Drevounia
Bratislava
CUT TO SIZES FOR PALLETS
Dimensions Thickness: 19, 20, 21 and
22 mm
Width: 75, 90, 95, 100 and 115 mm
Length: 800, 1 000, 1 100, 1 200 and
2 400 mm
Quality complies with the TP4 standard
of Drevounia Bratislava.
Dimensions con be adjusted upon the
client's request.
4. PRISMS
Dimensions Thickness: 95, 115 and 140
mm
Length: 2 400 and 3 000 mm
Quality complies with the TP5 standard
of Drevounia Bratislava.
Dimensions con be adjusted upon the
client's request.
5. POLES
Dimensions Length: 6, 6.5, 7, 8 m;
pin: 13 -16 cm
Length: 9, 10, 11, 12 m; pin: 16-18
cm
Convergence: max. 0.7/m
Quality meets the STN 491582 standard
|
